Best Setup for Your Indoor Grow Room

2
4171

Table of Contents

Best Setup for Your Indoor Grow Room





Do you struggle to find what size light goes with what size tent? Is my light too strong? Is it too weak? Sure, these are a few problems growers face. Is there any guide that can teach me the easiest way to make sure I have the proper light for the size of tent I want? Which is the best setup for an indoor grow room? Thankfully yes there is!

In this article, we put all that information in one place to make it as easy as possible for you to find the exact information you need. This way you can get to growing faster and begin to Love What You Grow.

Vivosun Grow Tent Instructions

The installation process for a Vivosun grow tent goes like this: First, lay out all the components such as the frame poles (labeled A, B, C, etc.), corner connectors, tray, cover, and hanging bars. Then, use the A-poles to connect the corner pieces to form the base frame, and install the vertical B-poles onto the four corners of the base frame. Connect the horizontal F-poles across the top to the B-poles, and install the E-poles and G-poles to create the roof frame on top. Next, drape the tent cover over the frame and zip it up using the heavy-duty zippers, and place the floor tray into the bottom of the tent. As needed, clip any hanging bars or supports onto the frame using the clips to install lights/filters, and secure the observation windows into the appropriate openings using the zippers/velcro. Finally, open up any vents or air intake holes as required for ventilation.

Vivosun tents feature a 600D tear-proof canvas exterior, 98% reflective diamond mylar interior lining, reinforced plastic corner connectors, heavy-duty metal zippers and double-stitching, and built-in tool pouches and ventilation ports. By carefully following the instructions, these tents can be easily assembled without tools to create a highly reflective, light-sealed optimal environment for indoor growing.



For your better choice, there is a simple equation that will show us the proper grow light strength required for a given tent. We can break them down into categories.

Categories of Grow Light Strength

  • Low efficacy, generic budget lights: 50-60 w/sq ft
  • Medium efficacy, “housing”-type lights: 30-40 w/sq ft
  • High efficacy, panel with quality diodes (eg. Samsung): 25-30 w/sq ft

Since Vivosun lights use Samsung diodes we will focus on that scale for this article. This formula will work with any brand of light but we will use our lights for quick reference. Let’s start with this as an example:

Let’s take a 2 ft x 2 ft tent. You would find the square foot by multiplying the length and width: 2 x 2 = 4 sq ft.

Then we do 4 x 50 =200 w for low efficacy, 4 x 30= 120 w for medium efficacy, and 4 x 25= 100 w for high efficacy.

This is the actual wattage from your outlet, so for a 2 x 2 tent then a VS1000 would do great.

Simple Formula of Vivosun Grow Tent

With this simple formula, it’s easy to make sure you have the perfect best setup. Let’s take a look at pairing lights and tents:

Tent sizeSQ FTWattageRecommended lightCU. FTCFMRecommended exhaust
Vivosun 30″ x 18″ x 36″ Grow Tent= 3.75 sq ft3.75*25=93.75 wVS1000x1
VS1000E x1
AeroLightx1
VS1500x1
11.25 ft³18Vivosun 4 inch exhaust
Vivosun 24″ x 24″ x 36″ Grow Tent= 4.0 sq ft4.0*25=100 wVS1000x1
VS1000Ex1
AeroLightx1
VS1500x1
12³19Vivosun 4 inch exhaust
Vivosun 2×2 Grow Tent 24″ x 24″ x 48″= 4.0 sq ft4.0*25=100 wVS1000x1
VS1000Ex1
AeroLightx1
VS1500x1
16 ft³25Vivosun 4 inch exhaust
Vivosun 32″ x 32″ x 63″ Grow Tent= 7.1 sq ft7.1*25=177.5 wVS1500x137.33 ft³60Vivosun 4 inch exhaust
Vivosun 36″ x 20″ x 63″ Grow Tent= 4.8 sq ft4.8*25=120 wVS1000x2
VS1000Ex2
AeroLightx2
VS2000x1
HCF1600x1
26.25 ft³45Vivosun 4 inch exhaust
Vivosun 3 x 3 Grow Tent 36″ x 36″ x 72″= 9.0 sq ft9*25=225 wVS2000x1
VS3000x1
54 ft³84Vivosun 4 inch exhaust & Vivosun 6 inch exhaust
Vivosun 4 x 2 Grow Tent 48″ x 24″ x 60″= 8.0 sq ft8*25=200 wVS1000x2
VS1000Ex2
AeroLightx2
VS2000x1
HCF3200x1
40 ft³63Vivosun 4 inch exhaust & Vivosun 6 inch exhaust
Vivosun 4 x 4 Grow Tent 48″ x 48″ x 80″= 16 sq ft16*25=400 wVS4000x1
VSFL4300x1
VSA-100x4
106.67 ft³179Vivosun 6 inch exhaust
Vivosun 5 x 2.7 ft 60” x 32” x 80” Grow Tent= 13 sq ft13*25=325 wVSFL4300x1
HCF3200x1
VS2000x2
86.11 ft³141Vivosun 6 inch exhaust
Vivosun 5 x 5 60″ x 60″ x 80″ Grow Tent= 25 sq ft25*25=625 wVSFD6500x1
HCF3200x2
166.67 ft³273Vivosun 6 inch exhaust & Vivosun 8 inch exhaust
Vivosun 8 x 4 96″ x 48″ x 80″ Grow Tent= 32 sq ft32*25=800 wVSFL4300x2
VS4000x2
213.33 ft³350Vivosun 8 inch exhaust
Vivosun 8 x 8 96″ x 96″ x 80″ Grow Tent= 64 sq ft64*25=1600 wVSFL4300x4
VS4000x4
426.67 ft³716Vivosun 8 inch exhaust
Vivosun 10 x 5 120″ x 60″ x 80″ Grow Tent= 50 sq ft50*25=1250 wVSFD6500x2333.33 ft³560Vivosun 8 inch exhaust
Vivosun 10 x 10 120″ x 120″ x 80″ Grow Tent= 100 sq ft100*25=2500 wVSFL6450x4666.67 ft³1119Vivosun 8 inch exhaust

This is just a basic guide. You can add more light or use a dimmer switch to get the right wattage or to have higher wattage for better canopy penetration.

Finding the right size exhaust fan can be a little more tricky. But we will break down the numbers so you can use it as a basic guide to save you the trouble.

Steps to Find the Right Fan

For this example, we will say that we want to scrub the air every minute in the tent.

First, we must find the Cubic Foot of the grow room. To do this we multiply Length x Width x Height. So on a 2 x 2 x 4 tent we would do

Fan CFM =  2 x 2 x 4 =16 ft³

Next, we must factor in the equipment, ( carbon filter, ducting, lights)

For carbon filters, the rule of thumb is that it reduces the efficiency of the extractor fan by 25%

Fan CFM = (16 CFM + (16×25%))= 20 CFM

For ducting the rule of thumb is to factor 1% reduction for every foot of duct. And for every bend, we factor 20% reduction. So a 5-foot duct with 1 bend would be a 25% reduction in efficiency

Fan CFM = (20 CFM + (20×25%))= 25 CFM

For HID lights we add a 10% reduction for 1000 w since they tend to run hotter.  For LED since they run cooler we only have to add a 7% reduction per 1000 w.

Fan CFM =(25 CFM + (25×10%)) = 27.5 CFM

Ideally, you would want a fan slightly higher than the final CFM this way if you choose to add equipment like a silencer or more ducting you can do so easily without having to replace the current exhaust fan.

I know this is a lot of technical information, but in all honesty, it’s not very difficult once you learn how to do it. This should allow you to pick your tent size and see the lights and exhaust for that particular tent. Hopefully, this will keep you from having to spend hours searching for the right information before you make the purchase.

The information above uses just our LED as an example but there is still the option of using HPS, CMH, or Fluorescent in your space. The wattage is still the same so you can still use this guide to help determine the right setup.
